| Frame size |
280-800MM |
| Output |
75-3150kW |
| Rated voltage |
380V/415V/660V/690V/1140V/3KV/3.3KV/6KV/6.6KV/10KV/10.5KV/11KV |
| Mounting arrangements |
IM B3 |
| Protection degree |
IP21/IP23/IP44/IP54/IP55/IP56 |
| Cooling Method |
IC01/IC016/IC611/IC616/IC666 |
| Number of poles |
4P/6P/8P/10P/12P |
| Insulation class |
F H |
| Ambient temperature |
Altitude should be lower than 1000 m above sea level; -15°C ~+40°C |
| Duty |
S1 |
| Service factor |
1.0 |
? Frequently Asked Questions
What is the output range of these industrial motors?
The motors offer a versatile power range from 75kW up to 3150kW, making them suitable for various heavy-duty industrial applications.
Which voltage options are available?
We provide a wide range of voltage configurations, including low voltage (380V-690V) and high voltage options (3KV-11KV) to meet global power standards.
What are the protection and cooling methods?
Our motors support multiple protection degrees from IP21 to IP56 and various cooling methods like IC611 or IC01, ensuring stable operation in diverse environmental conditions.
Can these motors operate at high altitudes?
The standard design is optimized for altitudes below 1000 meters above sea level with an ambient temperature range of -15°C to +40°C.
What duty cycle are these motors designed for?
These motors are designed for S1 continuous duty, providing reliable performance for long-term industrial operations.
What insulation classes are supported?
The motors are available with Class F or Class H insulation, offering high thermal stability and enhanced motor life.
